Pulmonary embolism diagnosis :
I had posted this case for discussion in our radiology group and most of the radiology residents were able to pick up finding. But is there more than meets the (radiologistโs) eye? Read on to find out. You can skip the detailed explanation and jump to the conclusion but I would suggest you read on. No harm in revising!
Introduction
Pulmonary embolism is a potentially life-threatening condition and is the third most cardiovascular condition causing death, following myocardial infarction and stroke. Clinical symptoms and risk factors for pulmonary embolism are discussed in detail elsewhere, we shall discuss the imaging features.
Radiographs:
- Not reliable for pulmonary embolism diagnosis, owing to poor sensitivity and specificity.
- Help to rule out other causes of chest pain like pneumothorax and pneumonia.
- Important from an academic reason as few examiners still like to ask named signs of pulmonary embolism (WHY!). I have mentioned a few mnemonics for remembering these. ย
- Hampton hump: peripheral wedge-shaped opacity corresponding to infarct
- Fleischner sign: Prominent pulmonary artery (FLUSHED pulmonary artery).
- Westermark sign: Regional oligaemia ย (reduced marks).
- Palla sign: Enlarged right descending pulmonary artery (PA prominent).
Conventional Pulmonary Angiography:
- Highly sensitive and specific.
- Not feasible in all patients.
- Reserved in patients where endovascular treatment is planned.
MRA:
- Technically difficult.
- Low sensitivity.
- Can be difficult to perform in the acute setting.
- Has similar results to that of CT pulmonary angiography if images have been acquired optimally and interpreted with expertise.
Nuclear Medicine: Ventilation-perfusion scanning
- Ventilation-perfusion scanning is preferred in younger patients and in pregnant patients as it is associated with less radiation exposure than CTPA.
- Lower sensitivity and specificity as compared to CTPA.
- Detailed description for V/Q scanning.
CT pulmonary angiography:
- Has replaced conventional pulmonary angiography as the reference standard for pulmonary embolism diagnosis because of its ease of performing and high sensitivity and specificity.
- Additional screening for lower limb DVT can be performed as well.
- Offers alternative diagnosis when pulmonary embolism is absent.
- CT pulmonary angiography protocol:
- Multidetector CT is preferred (at least 16 slices)
- Caudal-cranial direction: Most emboli are located in the lower lobes and, if the patient breathes during image acquisition, there is more excursion of the lower lobes compared with the upper lobes.
- IV access: 18- or 20-gauge catheter is preferred.
- Pulmonary embolism-specific window: Window width, 700; window level, 100ย
- Detailed protocols can be accessed in this AJR article and here.
- Diagnosis is straightforward in most cases.
- Criteria for pulmonary embolism diagnosis:
- Acute Pulmonary Embolism
- Arterial lumen occlusion with failure to enhance with/without dilatation of the artery.
- MIP images are good for diagnosis and documentation, especially coronal views (refer image below).
- Partial filling defects:
- โpolo mintโ sign: transverse view
- โrailway trackโ sign: longitudinal view.
- Lung parenchyma findings
- Peripheral wedge-shaped hyperdense areas and linear bands.
- Acute Pulmonary Embolism
- Signs of right heart failure (more than what meets the eye!)
- Patients are at risk for circulatory collapse and subsequent infarction can be life-threatening, hence prompt and early detection of acute right ventricular failure allows the implementation of the most appropriate therapeutic strategy
- Transthoracic Echocardiography is more specific, however, CT PA is comparable in sensitivity.
- Various imaging features on CT pulmonary angiography are useful for prognosis.
- There are more advanced findings on Cardiac CT however, the following are the most practical for routine radiology reporting.
- Findings that point to right ventricular strain include:
- Right ventricular dilatation : RV: LV ratio >=1 – Most reliable finding and should be included in all CT PA reports.
- Obstruction of โฅ 30% of the pulmonary vascular bed.
- Controversial and nonspecific findings:
- Reflux of contrast into hepatic veins or IVC
- Flattening or paradoxically convexity of the interventricular septum toward the left ventricle
- Pulmonary artery diameter more than 30mm.
- An abrupt increase in the diameter of the azygos vein and SVC.
Have a look at the first image once again now. The RV: LV ratio is more than one and there is flattening of the interventricular septum suggestive of right ventricular strain indicating a poor prognosis. More than what meets the eye!ย
-
Chronic Pulmonary Embolism
- Complete occlusion of a vessel that is smaller in caliber than adjacent patent vessels
- A peripheral, crescent-shaped intraluminal defect that forms obtuse angles with the vessel wall
- Thickened smaller caliber arteries due to recanalization
- Secondary signs
- Extensive collateral vessels
- Mosaic perfusion pattern
- Calcification within eccentric vessel thickening
- Ancillary findings:
- Pulmonary arterial hypertension: PAD diameter > 33mm or more than the adjacent ascending aorta.
- Pericardial effusion.
Flowchart for evaluation of Pulmonary embolism – Courtesy http://www.imagingpathways.health.wa.gov.au/
Pulmonary embolism differential diagnosis and mimics that can be diagnosed on CT:
- Pericarditis,
- Acute myocardial infarction,
- Aortic dissection.
- Esophagitis
- Esophageal rupture m
- Pneumonia
- Lung cancer
- Pleural disease
- Chest wall abnormalities such as rib fractures and metastatic deposits.
Evaluation of deep venous thrombosis:
- In the acute setting pulmonary artery embolism determines the cardiopulmonary status and mortality, however, the major risk of death is from recurrent PE. Hence evaluating abdominal and lower limb veins is essential for prognosticating patients with pulmonary embolism.
- Clot burden can be assessed by CT venography of the lower limbs in the same sitting or using US Doppler.
Pulmonary embolism treatment
- Depends on the hemodynamic condition of the patient.
- Treatment options include:
- Anticoagulation therapy
- IVC filters
- Thrombolytic therapy
- Embolectomy
- Read more about the treatment for pulmonary embolism.ย
Reporting template for CT pulmonary angiography from RadReport:
Intravenous contrast (agent and volume): [ย ย ย ย ย ย ]
[ย ย ย ย ย ย ]
[None. ]
Diagnostic quality: [Adequate | Suboptimal | Nondiagnostic]
[No acute or chronic pulmonary embolism. ]
Conclusion:
Pulmonary embolism diagnosis on CT pulmonary angiography is quite straightforward. Radiologists should also report additional findings that help prognosis, including the presence of right heart strain. It is essential to be a CLINICAL radiologist ourselves than writing “Clinical correlation is suggested”.ย
Companion radiology case quiz:
What is your diagnosis in this patient presenting with acute chest pain and breathlessness? You can answer in the comments or in theย radiology group
More resources for thoracic imaging:
- Normal Imaging Anatomy
- Cardiothoracic Radiology Cases and other resources from the Society of Thoracic Radiology
- Radiology spotters
- RadioGyan Thorax section
References and further reading:
- Textbook of Radiology and Imaging: 2-Volume Set by David Sutton
- Felson's Chest Roentgenology
- How I Do It: CT Pulmonary Angiography- AJR
- CT Angiography of Pulmonary Embolism: Diagnostic Criteria and Causes of Misdiagnosis
