Radiology Spotters Collection

IgG4 Autoimmune Pancreatitis and associated anomalies

Sausage shaped pancreas with a hypo-attenuating halo suggestive of autoimmune pancreatitis.

What is an IgG4 Autoimmune Pancreatitis ?

Auto-immune pancreatitis is a chronic immune-mediated fibroinflammatory disease primarily involving pancreas responding to steroid therapy.

What are the diagnostic criteria for autoimmune IgG4 pancreatitis?

The Mayo Clinic HISORt Criteria are used for confirming the diagnosis. Here are the details:

Mayo Clinic HISORt Criteria for IgG4 Autoimmune Pancreatitis


(1) Periductal lymphoplasmacytic infiltrate with obliterative phlebitis and storiform fibrosis (LPSP) OR

(2) Lymphoplasmacytic infiltrate with storiform fibrosis showing abundant (210 cells/HPF) IgG4-positive cells


Typical: diffusely enlarged gland with delayed (rim) enhancement; diffusely irregular, attenuated main pancreatic duct

Others: Focal pancreatic mass/enlargement; focal pancreatic duct stricture; pancreatic atrophy; pancreatic calcification; or pancreatitis

Serology: Elevated serum IgG4 level (>135 mg/dL)

Other Organ Involvement.

Response to steroids.

What are the two subtypes of autoimmune pancreatitis?

Type 1 (lymphoplasmacytic sclerosing pancreatitis) and type 2 (idiopathic duct-centric chronic pancreatitis).

  • Type 1 autoimmune pancreatitis is the pancreatic manifestation of IgG4-related disease.
  • Type 2 has a distinctly different histologic and clinical profile, with no elevation of serum IgG4 concentrations or presence of autoantibodies.
AIP type 1AIP type 2
Geographical distributionAsia > United States, EuropeEurope > United States > Asia
Age at presentation60-70 s40-50 s
GenderMale >> FemaleMale = Female
SymptomsJaundice, Abdominal painJaundice, Abdominal pain
SerologyIgG4, IgG,
Usually negative
Pancreatic imagesEnlarged
(focal, diffuse)
(focal, diffuse)
Pancreatic histologyLymphoplasmacytic sclerosingIdiopathic duct-centritic pancreatitis with
granulocyte epithelial lesion.
Sclerosing cholangitis,
retroperitoneal fibrosis,
interstitional nephritis,
Inflammatory bowel
Steroid responseExcellentExcellent
Type 1 IgG4 vs type 2 Autoimmune Pancreatitis

What are the other anomalies associated with IgG4 Pancreatitis?

IgG4 disease is a multi-system disorder. Following disorders have been described (Common disorders are highlighted):

  • CNS:
    • Hypertrophic pachymeningitis
    • Autoimmune hypophysitis
    • Orbital pseudotumor
  • Salviay / lacrimal glands:
    • Mikulicz’s disease
    • Kuttner’s tumor
  • Thyroid
    • Riedel’s thyroiditis
    • Hashimoto’s thyroiditis
  • Lungs
    • Pulmonary pseudotumor
    • Interstitial pneumoniaLymphadenopathy
  • Hepatobiliary:
    • Autoimmune pancreatitis
    • Sclerosing cholangitis
    • Liver pseudotumor
  • Retroperitoneal fibrosis
  • Tubulointerstitial nephritis
  • Inflammatory aortic aneurysm
  • Prostatitis, testicular involvement
  • Cutaneous pseudolymphoma

What is the management for IgG4 Autoimmune Pancreatitis?

IgG4 pancreatitis responds well to corticosteroids.

PACS Based Case Images (Arterial and Portal Venous Phase)

Sorry, you are trying to access a page that is for Basic Membership Quarterly, Basic Membership Yearly, and Support + Go Ad-Free members only. Join Now to get access
Already registered? Sign-in here.
Need help? Email me or use the contact us page.

Detailed discussion with video:

Subscribe Subscribe RadioGyan Radiology YouTube channel


  1. Head to toe IgG4 Autoimmune Pancreatitis
  2. Grainger & Allison’s Diagnostic Radiology
